5. a. If the "Auto''mode is selected:
A
CURSOR Pv
( screen 9 )
b. if the "Manual" mode is selected:
Use the cursor buttons to select the speakers from which to
emit the test tones and adjust the volume, (screen 10)
To adjust the volume:
C№^R Pv
To select the speaker;
CURSOR CURSOR
© ^
'The test ions is
emitted from
the speaker
whose indicator
is highlighted.
,The test tone is
emitted from
the speaker
whose indicator
is highlighted.
The level of each channel should be adjusted to 75 dB (C'-weighted, slow meter mode) on a sound level meter at the listening position.
If a sound level meter is not available adjust the channels by ear so the sound levels are the same. Because adjusting the subwoofer level test
tone by ear is difficult, use a well known music selection and adjust for natural balance.
NOTE: When adjusting the level of an active subwoofer system, you may also need to adjust the subwoofer's own volume control.
6. After the above settings are completed, press the ENTER button again.
The "System Setup Menu" screen (screen 2) reappears.
To cancel the settings, select "Level Clear" and "Yes" on the "Channel Level" screen, then make the settings again.
NOTES; ® The output channel levels for all the surround modes are set to the same conditions when the channel level setting on the system
setup menu is conducted,
® When the level clear operation is performed, all channel levels for all modes are set to 0 dB.
6-5 Digital input setup
Input the types of components connected to the digital input terminals,
1, Use the CURSOR buttons to specify "Digital Inputs" from the "System Setup Menu"
screen, (screen 11)
A
CURSOR Cv
2. Press the ENTER button.
System Setup Menu
Speaker Configuration
Delay Time
¿Channel Level
crDigital inputs
'^AC-3
Auto Tuner Presets
On Screen Display
Setup Menu Off
The "Digital input Setup" screen appears, (screen 12)
3. Use the cursor buttons to input the types of components connected to the digital input
terminals.
To select the input terminal: To select the type of component;
CURSOR CURSOR
ik Select "OFF" if nothing is connected.
( screen 11 )
Digital Inputs Setup
¡ t I COAXIAL I :
TldPTiCALl :
Default
¡VDPA)VPÌÌTVCT s 1Ì v ! aux T
^ |TAPe-i [VCR-11 jvCR-2ÌÌ OFF 1.
14 ( screen 12 )
