EOl-11014
STORE NAME /MESSAGE AND COMMERCIAL MESSAGE
PROGRAMMING OR CHANGING (Submode No. 1)
Any time outside a sale
Mode Lock: SET
Repeat for another line.
i| [@/FORJ
I
Submode No.
i Line No, i [ST] --------------------------
1 to 3
(See NOTE 2 below.)
1 to 7
*► Character Entries
(Max. 20 characters for each
line; see CHARACTER
ENTRIES, on page 18.)
1ST] > [AT/TLJ
Indicates the end of a line.
(Any unprogrammed parts of a line end will be
filled with blanks.)
For sequentially programming lines, the line number specification can be skipped.
NOTES: 1. For each line, a maximum of 20 regular-sized characters or 10 double-sized
characters ma/t)ë entered. A combination of both types is also available.
2. If the option “Store Name Print by RUBBER STAMP” is selected, no data can be
programmed for the store name/message. Therefore, enter 1 to 3 as Line No. for the
commercial message data only.
If the option “Store Name Print by DOT PRINTER” is selected, use 1 through 4 for the
store name/message and 5 through 7 for the commercial message data, as Line No.
3. If no commercial message is required on the receipt, program blanks for all three
lines. As a result no extra lines will be fed. If any one of the three lines is
programmed, the two other lines will cause line feeds.
4. The 4-line range assigned for the store name/message will be either printed or fed, as
long as the option “Store Name print by DOT PRINTER” is selected.
5. If any incorrect characters have been programmed, depress the fCJ key to clear all
the characters on a line and then re-enter characters from the beginning, or end the
line with an [ST] and re-program the entire line. The new data will be active.
6. When all the lines have been programmed, do a check by issuing a receipt. Only the
lines with errors need to be re-programmed; other lines will not be affected.
- 24 -
