Specifications
Section Detailed section Explanation
Terrestrial Input Signal Input Frequency
VHF: 174MHz to 230MHz
UHF: 520MHz to 820MHz
Transmission System DVB T/OFDM
Channel Assignment Australian Channel Assignment
Channel Bandwidth 7MHz
Channel Cffset +/ 125KHZ
Input Signal Level 90dBm - -20dBm
Antenna Input 75ffi Female lEC Connector (PAL Type)
Loop Output 75S Male lEC-Connector (PAL Type)
OFDM Spectrum Mode 2K and 8K Hierarchical
Modulation Modes QPSK, 16QAM, 64QAM
Guard Irrtervai Modes 1/32, 1/16, 1/8, 1/4 Active Symbol Duration
FEC Modes Rate 1/2, 2/3, 3/4, 5/6, 7/8
Video Algorithm MPEG-2 compatible MP@ML, MP@HL
Decoding Format All of Australia Digital TV Standard
Display Aspect Ratio 16:9 or 4:3
All of Australia Digital TV Standard
FID Video Output
HD ypbPr/HD VGA Simultaneous Output
Native Mode : lOSOi, 720p, 576p
CFiT Display : (1250), 1152i, 576p
SD Video Output
Common use of YPbPr/ FiGB - 576i component
output
Composite Video Output S video(Y/C), Composite Video(CVBS)
Audio Algorithm
MPEG-1 layers 1 and 2, MPEG-2 layers 2
Dolby Digital (AC 3)
Frequency Response 20Hz~ 20 kHz, < ±2dB
Sampling Frequency 32, 44, land 48 kHz
Analog Audio Output
Stereo (RCA phone jack), 2.0Vrms, >10K ohm
(2 Sets)
Digital Audio Output S/PDIF opticalfTOS Link), S/PDIF coaxial(RCA)
37
