■ MEMORY
• MEMORY CHANNELS
The 10 memory channels (1 through 9, and 0) are available
for data entry. Channel 1, 8 and 9 have the following func­
tions in addition to its ordinary function.
Channel 1 is the Priority Alert Channel.
Channel 8 is the lower, and channel 9 is the upper limit fre­
quency for the programmable band scan operation.
Channel 0 is the Odd Split channel.
Each memory channel can store RX Frequency, F. STEP
status, OFFSET, REVERSE switch status and TONE Fre­
quency (TH-41 5A/31 5A/21 5A).
• MEMORY ENTRY
1. Press the I m | key. The display will
indicate M and any memory channels
that contain data. (Ex. 1, 4, 7, 8, 9)
2. Press the desired memory channel
number (Ex. 5) within 5 seconds of
pressing the I
m | key. This will ac­
tually store the information into
memory.
□
□
QBE]
M
□
QBB
• MEMORY RECALL
Simply press the desired memory channel key and the radio
will switch to this frequency.
To return to the original operating frequency, press the
same memory channel key again.
Memory channel 0 stores both a transmit and a receive fre­
quency. This channel will allow operation on “Odd Split"
repeater channels.
1. Select the desired receiver frequency, tone frequency,
etc.
2. Press the I m I and then the 10 I key to store this part
of the data into memory.
3. Select the desired transmitter frequency.
4. Press the I m | key.
5. Within 5 seconds of pressing the | m I key press and
hold the PTT switch. The PTT switch will not initiate
transmit during the programming of this channel.
6. Press the 10 I key within 5 seconds of pressing the
PTT switch to complete the operation. After you have
pressed the 10 I key in this step you may release the
PTT key.
• ODD SPLIT MEMORY CHANNEL
To operate on memory channel 0 you
need only press the 10 I key. The —
and the + indicators will turn on to in­
dicate that this memory channel now
contains odd split frequency data.
To cancel this odd split data simply store a new frequency
into the memory channel.
15
