Installation

2. Secure bracket with 2 screws adequate for mounting surface (i.e., for wood

floor use wood screws, for concrete floor use concrete anchors and screws).

\ rearwal

\\\

cabinet wall

-ii i)-.-.

\\\

i o j i f I

jJiO

I I j (j; I

! U

U|

%

i

flush against

j cabinet wall

1 9/16" (39,7 mm)

from rear wall to center of screw hole

floor

anti-tippin g
device

Figure 8: Anti-Tip Bracket

Ventilation Recommendations

We strongly recommend the installation of a ventilation hood above this appli­
ance, For most kitchens a certified hood rating of not less than 300 CFM is recom­

mended, The range hood must be installed according to instructions furnished

with the hood.

Installation Procedure

Apply Foam Tape

Apply foam tape to underside of cooktop trim in one continuous piece.

Install Backwall Trim

Note:

This step is only required if the countertop does not connect behind
the range (i,e,; when replacing a free-standing range). See “Cabinet

Requirements” on page 7 for more information

English 10
