Installation
Allow a minimum of 30 inches between cabinets where range is to be installed^.
kr""
23 1/16"
(585.4 mm)
r
30'
Figure 5: Cutout Requirements - Typical installation
Note;
The slide-in range can also replace a freestanding range. In this
case, verify that the opening is at least 30 inches.
30" (76.2 cm) min.
Figure 6; Cutout Requirements - Replacing a Free-Standing Model
1 .In Canada, a clearance of 12 mm from range sidewall to cabinet is required.
