Connecting Your Equipment

Connecting DVD 7.1 Channel (5.1 ch for VSX-D710S) Components

DVD and LD discs are compatible with both 2 channel and 7 1 channel audio output formats Connections can be
made from a DVD player/multi-channel decoder equipped with 7 1 analog outputs to the 6 1 analog inputs on this

unit (the surround back channel is mono on the VSX-D810S/D850S models so we refer to it as 6 1 ch) You need to

connect both the left and right surround back channels for the VSX-D810S/D850S models but the sound from this
channel will only be mono Always make sure that the receiver is switched off and unplugged from the wall outlet

before making or changing any connections

The arrows indicate the direction of the audio signai

VSX-D710S

DVD/muiti channei
decoder with 51 channei
anaiog output jacks

VSX-D810S/D850S

DVD/muiti channei

decoder with 7 1 channei
anaiog output jacks

MEMO:

• The 7 1 channel (5 1 channel for VSX-D710S) input can only be used when DVD 7 1 ch (5 1 channel for VSX-

D710S) input is selected

• For 6 1 channel output select the SB Ich setting (see p 20) In this case you can connect the single surround back

speaker to either the left or right surround back terminals
