Parts List 119.16433010
Key Qty Part No. Description
C2 1 S7004-042D-001 Side Burner Cover
C3 1 S7001-042D-017 Side Burner Outer Frame Assembiy
C4 1 *ASMD0085-01 Side Burner
C5 1 *ASMD0085-02 Side Burner Upper Controi Panei
C6 1 PLABS0090-001 Controi Knob Seat- Large
C7 1 PLABS0103-001 Controi Knob - Large
C8 1 S7005-F00B-026 Side Burner Lower Controi Panei
C9 1 *ASMC0012-08 Towei Bar Flandle
CIO 1 SE0084-012 Side Burner Cooking Grate
Cll 1 *ASMD0085-03 Side Burner Inner Frame
C12 1 SE0083 Side Burner Eiectrode
C13 2 SB0045-001 Side Burner Stopper
D1 1 S7002-042D-005 Side Sheif Assembiy
D2 1 *ASMD0085-02 Side Sheif Upper Front Panei
D3 1 S7005-000B-027 Side Sheif Lower Front Panei
D4 1 *ASMC0012-08 Towei Bar Flandle
D5 3 SE0123-002 "S" Hook
El 1 *ASMC0085-01 Cabinet Assembly
E2 2 SE0257 Swivel Caster
E3 1 S4025-042D-002 Cabinet Door Stop
E4 2 SE0055 Swivel Locking Caster
E5 1 *ASMC0085-02 Cabinet Toe Plate
E6 1 SE0080-001 Regulator and Hose Support Ring
E7 1 SE0290-002 Cylinder Support Ring
E8 2 SE0150 Magnetic Door Stop
E9 1 *ASMC0085-03 Cabinet Front Crossbar
ElO 1 SE9027-011 Condiment Basket
Ell 1 *ASMC0085-04 Cabinet Left Door
E12 1 *ASMC0085-05 Cabinet Right Door
E13 2 PLABS0092N-001 Cabinet Door Handle
E14 1 *ASMC0085-06 Cabinet Back Panel
E15 1 SE0019-001 Manual Igniter Stick
E16 2 SE0289-001 Door Bottom Pin
E17 2 SE0288-001 Door Top Pin
Not Pictured
N/A 1 ASMF085 Hardware Pack
N/A 1 RNA0103 Manual
If you are missing hardware or have damaged parts after unpacking griii, caii 1-800-933-0527 for repiacement.
To order repiacement parts after using griii, caii 1-800-4-MY-HOME®.
