Parts List 119.16433010
Key
Qty
Part No.
Description
Al
1
*ASMA0085-01
Flood Assembly
A2
2
*ASMA0014-03
Flood Bolt Assembly
A3
1
CA0045-001
Flood Flandle Seat Assebmiy
A4
2
FLPP0114
Flood Flandle Fleat Insulator
A5
1
SE0213
Thermometer
A5
1
CA0045-002
Thermometer Seat
kl
1
*ASMA0014-05
Flood Flandle
B1
1
*ASMB0085-01
Firebox Assembly
B2
1
SC1020
Gas Manifold Assembly
B3
1
*ASMB0085-02
Firebox Front Fleat Shield
B4
1
SD0051
Rôtisserie Burner
B5
1
*ASMB0085-03
Rôtisserie Burner Orifice Support
B5
1
SC0097
Rôtisserie Burner Orifice
B7
1
S1027-037D-005
Rôtisserie Burner Cover
B8
3
SD0024-A
Main Burner
B9
3
SE9009
Main Burner Electrode
BIO
1
S1018-000C-025
Grease Tray
Bll
3
PLABS0090-001
Control Knob - Large
B12
1
PLABS0103-001
Control Knob - Small
B13
1
PLABS0104-001
Control Knob Seat - Small
B14
3
FA0121-001
Control Knob Seat - Large
B15
1
SE0285-012
Warming Rack
B15
1
SE0287-013
Grease Pan Bracket
B17
1
S1020-023D-004
Grease Pan
B18
1
*ASMB0085-04
Electronic Igniter Wire Set
B19
1
SB0131B
Electronic Igniter Button
B20
1
SE0078
Electronic Igniter
B21
1
*ASMB0085-05
Main Burner Control Panel top Panel
B22
1
*ASMB0085-05
Main Burner Control Panel
B23
3
S1007-012E-016
Fleat Diffuser
B24
1
SCOlOl
Side Burner Valve
B25
1
SE0148
Regulator and Flose Assembly
B25
2
CI0018-012
Cooking Grate
B27
1
SCOlOO
Rôtisserie Burner Flame Sensor
B28
1
SE0237Z
Rôtisserie Burner Electrode
B29
1
*ASMB0085-07
Rôtisserie Burner Electrode Protection Box
B30
1
SHllOO-A
Rôtisserie Burner Stem
B31
1
S1045-000C-001
Rôtisserie Burner Electrode Support
B32
4
FE0025M
Flood Bumper
Cl
1
SE0153-002
Side Burner Cover Pin
