STK17TA8
Document #: 001-52039 Rev. ** Page 3 of 23
Absolute Maximum Ratings
Voltage on Input Relative to Ground ................–0.1V to 4.1V
Voltage on Input Relative to V
SS
.........–0.5V to (V
CC
+ 0.5V)
Voltage on DQ
0-7
or HSB.....................–0.5V to (V
CC
+ 0.5V)
Temperature under Bias ............................... –55 °C to 125°C
Junction Temperature ................................... –55 °C to 140°C
Storage Temperature .................................... –65 °C to 150°C
Power Dissipation............................................................. 1W
DC Output Current (1 output at a time, 1s duration)..... 15mA
RF (SSOP-48) Package Thermal Characteristics
θ
jc
6.2 C/W; θ
ja
51.1 [0fpm], 44.7 [200fpm], 41.8 C/W [500fpm]
Note: Stresses greater than those listed under “Absolute
Maximum Ratings” may cause permanent damage to the device.
This is a stress rating only, and functional operation of the device
at conditions above those indicated in the operational sections
of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
reliablity.
DC Electrical Characteristics
(V
CC
= 2.7V-3.6V)
Symbol Parameter
Commercial Industrial Units Notes
Min Max Min Max
I
CC1
Average V
CC
Current 65
50
70
55
mA
mA
t
AVAV
= 25 ns
t
AVAV
= 45 ns
Dependent on output loading and
cycle rate. Values obtained
without output loads.
I
CC2
Average V
CC
Current during
STORE
3 3 mA All Inputs Don’t Care, V
CC
= max
Average current for duration of
STORE
cycle (t
STORE
)
I
CC3
Average V
CC
Current at t
AVAV
=
200ns
3V, 25°C, Typical
10 10 mA W ≥ (V
CC
– 0.2V)
All Other Inputs Cycling at CMOS
Levels
Dependent on output loading and
cycle rate. Values obtained
without output loads.
I
CC4
Average V
CAP
Current during
AutoStore™ Cycle
3 3 mA All Inputs Don’t Care
Average current for duration of
STORE cycle (t
STORE
)
I
SB
V
CC
Standby Current
(Standby, Stable CMOS Levels)
3 3 mA E ≥ (V
CC
-0.2V)
All Others V
IN
≤ 0.2V or ≥
(V
CC
-0.2V)
Standby current level after
nonvolatile cycle complete
I
ILK
Input Leakage Current ±1 ±1 mA V
CC
= max
V
IN
= V
SS
to V
CC
I
OLK
Off-State Output Leakage Current ±1 ±1 mA V
CC
= max
V
IN
= V
SS
to V
CC
, E or G ≥ V
IH
V
IH
Input Logic “1” Voltage 2.0 V
CC
+ 0.5 2.0 V
CC
+ 0.5 V All Inputs
V
IL
Input Logic “0” Voltage V
SS
–0.5 0.8 V
SS
–0.5 0.8 V All Inputs
V
OH
Output Logic “1” Voltage 2.4 2.4 V I
OUT
= – 2 mA (except HSB)
V
OL
Output Logic “0” Voltage 0.4 0.4 V I
OUT
= 4 mA
Note: The HSB pin has I
OUT
=-10uA for V
OH
of 2.4V, this parameter is characterized but not tested.
Note: The INT is open-drain and does not source or sink high current when interrupt Register bit D3 is below.
