Care and cleaning of the range.
Oven Bottom
The oven bottom has a porcelain-enamel
finish. To make cleaning easier, protect the
oven bottom from excessive spillovers by
placing a cookie sheet on the rack below the
rack you are cooking on. This is particularly
important when baking a fruit pie or other
foods with a high acid content. Hot fruit
fillings or other foods that are highly acidic
(such as tomatoes, sauerkraut and sauces
with vinegar or lemonjuice) may cause pitting
and damage to the porcelain-enamel surface
and should be wiped up immediately.
To clean up spillovers, use soap and water, an
abrasive cleaner or soap-filled scouring pad.
Rinse well to remove any soap before self­
cleaning.
Lift-Off Lower Oven Door (on some models)
The door is very heavy. Be careful when
removing and lifting the door.
Do not lift the door by the handle.
To remove the door:
|~7] Fully open the door.
r^ Pull the hinge locks down toward the door
'—' frame, to the unlocked position. A tool,
such as a small flat-blade screwdriver,
may be required.
Firmly grasp both sides of the door at the
top.
Close door to the door removal position,
which is halfway between the broil stop
position and fully closed.
Lift door up and out until the hinge arm
is clear of the slot.
To replace the door:
Firmly grasp both sides of the door at the
top.
With the door at the same angle
as the removal position, seat the
indentation of the hinge arm into the
bottom edge of the hinge slot. The notch
in the hinge arm must be fully seated into
the bottom of the slot.
Fully open the door. If the door will not
fully open, the indentation is not seated
correctly in the bottom edge of the slot.
Push the hinge locks up against the front
frame of the oven cavity to the locked
position.
Close the oven door.
Hinge —
lock
-
Hinge
arm
Push hinge locks up to lock.
Lift-Off Upper Oven Door (on some models)
To remove the door:
[f\ Fully open the door.
Lift up on the hinge lock toward the oven
frame until they stop.
/
8
close the door to 45 degrees (you will feel
the door stop). The hinge lock will contact
the oven frame.
On both sides of the door, press down on
the release buttons on each hinge.
Lift door up until it is clear of the hinge.
Pull on hinge arms slightly to relieve
pressure on the locking tabs.
Push the hinge locks down onto
the hinge.
Push the hinges in toward the unit
so they are closed.
To replace the door.
Pull the hinges down away from the oven
frame to the fully open position.
Lift up on the hinge locks toward the oven
frame until they stop.
The hinges will release to the 45-degree
position. The hinge locks will contact the
oven frame.
Slide the door back onto the hinges. Make
sure the buttons pop back out.
Fully open the door.
0
z
T
Push the hinge locks down onto the hinge.
Close the oven door.
Push in
