GEAppliances.com
Be sure electrical power is off and all surfaces are cool before cleaning any part of the range.
awarning If your range Is removed for cleaning, servicing or any reason, be
sure the anti-tip device is reengaged properly when the range is replaced. Failure to take
this precaution could result in tipping of the range and cause injury.
To check if the bracket is installed and engaged properly, carefully tip the range forward. The
bracket should stop the range within 4 inches. If it does not, the bracket must be reinstalled.
If the range is pulled from the wall for any reason, always repeat this procedure to verify the
range is properly secured by the anti-tip bracket.
If your range has no anti-tip bracket, call 1.800.626.8774 to receive one at no cost.
Sealed Burner Assemblies (on some models)
Turn all controls OFF before removing the
burner parts.
The round side burner caps and burner
heads can be lifted off, making them easy to
clean. The electrodes ore not removable.
The oval center burner head and cop
assembly con be lifted off, making it easy
to clean. The burner electrode is not
removable.
The tri-ring burner inner cop con be lifted
off for cleaning, the outer cop and base
assembly con be lifted off the cooktop as one
piece for cleaning purposes.
ACAUTION
Do not operate the
cooktop without all burner parts and grates
in place.
Tri-ring base
(on some models)
The electrode of the spark igniter is
exposed when the burner head is
removed. When one burner is turned
to LITE, all the burners spark. Do
not attempt to disassemble or clean
around any burner while another
burner is on. An electric shock may
result, which could cause you to knock
over hot cookware.
■ Electrode
Chef's
griddle
Burner head
cap and
electrode
ACAUTION
Do not remove
tri-ring or bridge burner cap from head.
The tri-ring or bridge burner head and cap
assembly can be lifted off, making it easy to
clean. The electrode is not removeable.
29
