Installation Instructions
E Replacing the Oven Door
NOTE: The oven door is heavy. You may
need help lifting the door high enough to
slide it into the hinge slots. Do not lift the
door bythe handle.
D1
D2
Lift the oven door by
placing one hand on
each side. The door is
heavy, so you may need
help. Do not lift the door
by the handle.
With the door at the some angle as
the removal position, which is most of the
woyclosed, seotthe notch ofthe hinge
arm into the bottom edge of the hinge
slot. The notch ofthe hinge arm must be
fully seated into the
bottom ofthe slot.
Hinge Arm
Bottom Edge
ofSIot
Hinge Notch
D3
D4
Open the oven door os for os it
will open.
Push the hinge locks up against the front
frame ofthe oven cavity, to the locked
position.
Hinge in
Locked Position
D5
Notch of Hinge
Securely Fitted int^
Bottom of Hinge
Slot
Close the oven door.
