GE ZET1SMSS User Manual
Installation instructions, Before you begin, Parts included
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
Installation
Instructions
30” (76.2 cm) Built-In
Wall Oven
ZETl, ZET2
Ifyou have questions, call 1.800.GE.CARES or visit our website at: ge.com
Before You Begin
Read these instructions carefully and completely.
.IMPORTANT
—Save these
instructions for local inspector's use.
.IMPORTANT
—Observe all
governing codes and ordinances.
. Note to Installer—Be sure to leave these
instructions with the consumer.
. Note to Consumer-Keep these
instructions for future reference.
. Proper installation is the responsibility
ofthe installer and productfailure due
to improper installation is NOT covered under
warranty.
. NOTE—This appliance must be properly
grounded.
.ATTENTION INSTALLER
All electric wall ovens must be hard wired
(direct wired) into an approvedjunction box. A
plug and receptacle is NOT permitted on these
products.
Parts Included
(Appearance may vary.)
3/4" Wood
Screws
(8-18 X .750 flat-head
Phillips wood screws)
5/8" Wood
Screws
(8A8 X .625 truss-head
Phillips wood screws)
Metal Bottom
Trim Assembly
Materials Needed
Wire Nuts
StrainReliefClampfor
Junction
1/2" conduit
Box
35" (91 cm) of
String
31-10842
04-12 GE
