7
10. Carefully pull the aileron y-connector through
to the servo opening.
11. Plug the aileron servo into the y-connector.
Use tape on the plug to make sure it does not
come loose.
12. Pull the aileron y-connector back into the wing
and seat the servo in the opening.
13. Screw the servo in place using the hardware
supplied with the radio.
14. Install the pushrod connector on your servo
arm. The plastic push-on nut will retain it.
15. Make a 90 degree bend 1/4” long in the end
of one of the 1/32 x 5-1/2” wires and install in
the control horn. Use the nylon swing in keep-
er to retain the wire.
16. Insert the other end of the pushrod in the
pushrod connector you installed on the servo
arm. Install the arm on the servo. Center the
servo with the radio and center the aileron.
Tighten the screw on the servo connector.
Install the screw to retain the servo arm on the
servo. Cut the excess wire off the pushrod.
Caution:
Make sure the nylon nut is pushed all the
way onto the pushrod connector.
