16
4. Place the canopy on hatch and tape in place till
dry. Use wax paper at the rear to make sure
you don’t glue the canopy to the turtle deck.
use wax paper
Receiver-Battery Installation
servos receiver in
foam
battery
speed control
1. The receiver can go just in front of the ser-
vos, the battery will fit just forward of the
receiver and the speed control can go in
the nose compartment.
Important: The battery must have some
sort of retainer over the top, Don’t depend
on the canopy to hold it in place.
2. The battery can be taped to the top of the
wing using double sided tape, this is how
we did it. You can also glue velcro( not
included) to the top of the wing, or you
can glue a small piece of wood over the
top.
CG and Control Throws
The CG should be 3-1/2” to 4” behind the leading
edge at the fuselage. Our model balanced and
flew with no added weight set up as shown.
Notice:
The plane is very responsive with a
high rate of roll, so be ready for snap-
py performance. Do not fly on high
rates on your first flight.
Elevator Low Rate 1/2” each way
High Rate All you can get
Ailerons Low Rate 3/8” each way
High Rate All you can get
Rudder Low Rate 1” each way
High Rate All you can get
Important:
Don’t glue the canopy to the hatch without
the hatch being installed on plane. If you
glue it off the plane it might not fit when
you try to install it.
