Braeburn 3220 Installer Guide User Manual
Page 10
No. Installer Setting
Factory
Setting
Comments
(
Notes follow this table)
Default
Options
(More information follows this table)
11 Compressor Power Outage
oF CPOP
oF CPOP
Disables Power Outage Lockout Delay
Protection
[notes 3, 5]
on CPOP
Enables Power Outage Lockout Delay
12 AC Power Interrupt
AC oF MONR AC oF MONR Disables AC Power Interrupt Warning
Warning
[note 5]
AC on MONR Enables AC Power Interrupt Warning
13 Compressor Short
5 CSCP
5, 4, 3, 2 or Select a compressor short cycle protection delay of 5,
Cycle Protection
[note 6]
0 CSCP
4, 3, 2 or 0 minutes
14 Residual Cooling
60 FAN
90, 60, 30 Select a Residual Cooling Fan Delay of 90, 60,
Fan Delay
[note 6]
or
0 FAN
30 or 0 seconds.
15 Indoor Remote Sensor
I SENS
I SENS
Temperature is sensed from thermostat only.
Control*
[note 7]
E SENS
Temperature is sensed from remote sensor only.
A SENS
Temperature is combined with the thermostat and
the remote sensor.
16 Lockout Security Level
2 LOCK
2 LOCK
If locked – Complete lockout is enabled
1 LOCK
If locked – Partial lockout is enabled (SpeedBar
®
is
still functional)
17 Auto Changeover
3 BAND
2, 3, 4 or 5 Select a Dead Band of 2°, 3°, 4° or 5˚ F
Dead Band
[note 8]
BAND
(1°, 2° or 3° C) for Auto Changeover mode.
18 Compressor Balance
NO BALC
NO BALC
Disables Balance Points
Point
[notes 3, 9]
15-50 BALC Select a Compressor Balance Point of 15°- 50°F
(-9°-10° C)
19 Auxiliary Heat Balance
NO BALA
NO BALA
Disables Balance Points
Point
[notes 3, 9]
70-40 BALA Select a Auxiliary Heat Balance Point of 70°- 40° F
(21°- 4° C)
20 Heat Set Point Upper Limit
90LIM
90-60 LIM Select a Heat Set Point Upper Limit of 90°-60° F (32°-10° C)
21 Cool Set Point Lower Limit
45LIM
45-80 LIM Select a Cool Set Point Lower Limit of 45°-80° F (7°-27° C)
[note 6]
*When a Braeburn
®
outdoor sensor is connected, the thermostat automatically recognizes it. Press
BACK
and
NEXT
at the same
time to display outdoor temperature.
NOTE: Additional options such as Service Monitors, Setting the lock code, etc. are located in the User Settings –
See User manual for information on setting these options.
NOTES - Installer Settings
1 Only available if a 2 or 3 stage system type was selected in option 3.
2 Only available if a Conventional system was selected in option 3.
3 Only available if a 2 or 3 stage Heat Pump system was selected in option 3.
4 Only available if a Heat Pump system was selected in option 3.
5 Only available if the 24 Volt AC common wire is connected to the C terminal.
6 Not available if a Heat Only Hydronic system is selected in option 3.
7 Only available if a Braeburn
®
indoor remote sensor was connected.
8 Only available if auto changeover was enabled in option 2.
9 Only available if a Braeburn outdoor sensor was connected.
Detailed Explanation of Installer Settings (also see NOTES above):
1 Temperature Scale – Selects a temperature scale of either °F or °C.
2 Auto Changeover – Selects auto changeover on or off. When auto changeover mode is enabled and
selected, the system automatically switches between heating and cooling modes. There is a 5 minute delay
when switching from heating to cooling or cooling to heating in auto changeover mode.
NOTE: Also see “Auto Changeover Dead Band” in option 17.
Installer Guide 10
