H19 Series BASO Automatic Shutoff Pilot Gas Valve Installation Instructions 5
Technical Specifications
Product
H19 Series BASO Automatic Shutoff Pilot Gas Valve
Maximum Operating
Pressure
0.5 psi (35 mbar)
Valve Body
Aluminum
Permissible Ambient
(Surface) Temperature
H19A_ 32 to 150°F (0 to 66°C)
H19ME -40 to 150°F (-40 to 66°C)
Recommended
Thermocouple Lead
Length
K15: 12 to 48 in. (305 to 1,220 mm)
K16: 12 to 72 in. (305 to 1,830 mm)
K19: 18 to 72 in. (457 to 1,830 mm)
Inlet and Outlet Pipe Size
3/8 x 3/8 in. NPT
Types of Gas
Natural, Liquefied Petroleum (LP), and LP gas-air mixtures
Packaging
Bulk pack supplied to original equipment manufacturer (individual pack optional)
Bulk Pack Quantity
60
Bulk Pack Weight
30 lb (14 kg)
Agency Listings
CSA (AGA/CGA) Certificate Number 229521-1656106
UL Recognized File Number MH2926
Specification Standards
ANSI Z21.78, CSA 6.20
ANSI Z21.21, CSA 6.5
ANSI Z21.20
CAN1-6.4)
UL Standard 372
Performance specifications are nominal and conform to acceptable industry standards. All agency certification of BASO products is performed
under dry and controlled indoor environmental conditions. Use of BASO products beyond these conditions is not recommended and may void
the warranty. Product must be protected if exposed to water (dripping, spraying, rain, etc.) or other harsh environments. The original
equipment manufacturer or end user is responsible for the correct application of BASO products. Consult BASO Gas Products LLC for
questionable applications. BASO Gas Products LLC shall not be liable for damages or product malfunctions resulting from misapplication or
misuse of its products.
Refer to the H19 Series BASO Automatic Shutoff Pilot Gas Valve Product Bulletin (BASO-PB-H19) for necessary information on operating and
performance specifications of this product.
