6 G93 Series BASOTROL Combination Automatic Gas Valve Installation Instructions
Technical Specifications
Product G93 Series BASOTROL Combination Automatic Gas Valve
Maximum Operating
Pressure 0.5 psi (35 mbar)
Valve Body Aluminum
Permissible Ambient
(Surface) Temperature CSA: 32 to 155ºF (0 to 68ºC)
UL: 32 to 125ºF (0 to 52ºC)
Available Magnetic
Operator Cover Styles Aluminum side conduit hub
Aluminum top conduit hub
aluminum top without conduit hub
Aluminum side outlet with eyelet
Steel top conduit hub
Plastic with 1/4 in. (6.35 mm) male quick-connect terminals
Electrical Rating 25 VAC, 60 Hz, 0.3 ampere draw
120 VAC, 60 Hz, 0.05 ampere draw
240 VAC, 60 Hz, 0.03 ampere draw
208/240 VAC, 60 Hz, 0.037 ampere draw
Recommended
Thermocouple Lead
Lengths K15: 12 to 48 in. (305 to 1,220 mm)
K16: 12 to 72 in. (305 to 1,830 mm)
K19: 18 to 72 in. (457 to 1,830 mm)
Wiring Connections 1/4 in. (6.35 mm) male quick-connect terminals or
30 in. (762 mm) lead wires (other lengths are optional)
Regulator Adjustment 3 to 6 in. W.C. (7.5 to 15 mbar), top and bottom adjust regulator, natural gas
6 to 12 in. W.C. (15 to 30 mbar), top adjust regulator, LP gas
8 to 12 in. W.C. (20 to 30 mbar), bottom adjust regulator, LP gas
Inlet and Outlet Body
Connections 1/2 x 1/2 in. NPT
Types of Gas Natural, Liquefied Petroleum (LP), and LP gas-air mixtures
Packaging Bulk pack supplied to original equipment manufacturer (individual pack optional)
Bulk Pack Quantity 32
Bulk Pack Weight 51 lb (23 kg)
Agency Listing CSA Certificate Number 229521-1656066 (excludes G93H_ _)
UL File Number MH2926
Specification Standards ANSI Z21.78, CSA 6.20
UL Standard 372 and 429
Performance specifications are nominal and conform to acceptable industry standards. All agency certification of BASO products is performed
under dry and controlled indoor environmental conditions. Use of BASO products beyond these conditions is not recommended and may void
the warranty. Product must be protected if exposed to water (dripping, spraying, rain, etc.) or other harsh environments. The original
equipment manufacturer or end user is responsible for the correct application of BASO products. Consult BASO Gas Products LLC for
questionable applications. BASO Gas Products LLC shall not be liable for damages or product malfunctions resulting from misapplication or
misuse of its products.
Refer to the G93 Series BASOTROL® Combination Automatic Gas Valve Product Bulletin (BASO-PB-G93) for necessary information on
operating and performance specifications for this product.
