BGD278 Series BASOTROL CE Approved Gas Valve Installation Instructions 5
Technical Specifications
Product
BGD278 Series BASOTROL CE Approved Gas Valve
Types of Gas
2nd (Natural Gas), and 3rd (LP Gas) Family Gases
Permissible Ambient
(Surface) Temperature
-29 to 79°C (-20 to 175°F )
Electrical Ratings
12 VDC, 1.0A
25 VDC, 0.675A
25 VAC, 50/60 Hz, 0.595A
120 VAC, 50/60 Hz, 0.13A
240 VAC, 50/60 Hz, 0.063A
Rated Inlet Pressure
North America:
Europe:
Australia:
0.5 psi
35 mbar
3.5 kPa
Maximum Working
Pressure (CE)
100 mbar
Maximum Differential
Pressure
20 mbar (2 kPa [8 in. W.C.])
Reverse Pressure Ratings
50 mbar (5 kPa [20 in. W.C.]); Class B (EN 126 and 161);
Class 2 (AS 4624 and AS 4629)
Regulator Classification
Class C (EN 126); Adjustable, Class 2, Grade 20 (AS 4624)
Regulator Setting
Factory set to customer’s specification
Regulator Adjustment
Range
Bottom Adjust Regulators:
Top Adjust Regulators:
7.5 to 15 mbar (0.75 to 1.5 kPa [3 to 6 in. W.C.])
20 to 30 mbar (2.0 to 3.0 kPa [8 to 12 in. W.C.])
7.5 to 15 mbar (0.75 to 1.5 kPa [3 to 6 in. W.C.])
15 to 30 mbar (1.5 to 3.0 kPa [6 to 12 in. W.C.])
Body Connections
1/2 NPT, 1/2 BSPP (Thread ISO 7-Rp); or 1/2 BSPT (Thread ISO 7-Rc) with Flange Connection
Holes (M4 x .07 mm pitch x 6 mm deep)
3/4 NPT or 3/4 BSPT (Thread ISO 7-Rc)
Valve Torsion Group
Group 2 (EN 126 and EN 161)
Pressure Connection
1/8 BSPP (Thread ISO 7-Rp), 1/8 BSPT (Thread ISO 7-Rc),
1/8 NPT Left-hand and/or Right-hand, or M5 x 0.8 Bottom
Pilot Connections
1/8 BSPP (Thread ISO 7-Rp), 1/8 BSPT (Thread ISO 7-Rc),
1/8 NPT Left-hand and/or Right-hand, or 1/4 in. cc Fitting Bottom
Dirt Strainer
0.036 in. (0.9 mm) Mesh (CE only or upon request)
Operating Time Rating
100% Continuous
Valve Timings
Closing Time
Opening Time
Dead Time
<1 Second
<1 Second
<1 Second
Power Ratings
15 VA per Coil (except 25 VDC, 17 VA)
Electrical Connections
3-Tab Solenoid Coil
2-Tab Solenoid Coil
2 x 1/4 in (6.35 mm) + 1/4 in. (6.35 mm) Earth Ground
2 x 1/4 in. (6.35 mm)
Coil Insulation Class
Class F
Type of Gas
2nd (Natural Gas), and 3rd (LP Gas) Family Gases
Accessories
Conversion Kits
Natural Gas to LP Gas:
LP Gas to Natural Gas:
Non-Regulation:
Top Adjust Regulator
Bottom Adjust Regulator
Top Adjust Regulator
Bottom Adjust Regulator
Top or Bottom Adjust Regulator
Y71GF-4
Y71GF-3
Y71QH-2
Y71QH-3
Y71AA-5
Packaging
Bulk pack supplied to original equipment manufacturer (individual pack optional).
Bulk Pack Quantity
32 per carton
Bulk Pack Weight
37 kg (82 lb) per carton
