VAX Matrix Switching System—User Manual
30
Model
Technical Specs
VAX-2088 VAX-2084 VAX-2044
Max. Output Level +22dBu（Balanced or Unbalanced Connection）
Control Type
Serial Control
Connector
RS-232，9-Pin Female D Type Connector
Baud Rate and
Protocol
9600bps, no odd or even calibration address，8bit
transmission address，1bit stop address
Serial Control
Structure
TX，RX，GND
Control Procedures
《AV Matrix》
Specifications
Power 100VAC~240VAC,50/60Hz，International Auto-Switch
Temperature Storage, Operating Temp.: -40℃~+85℃
Humidity Storage, Operating Humidity:10%~90%
Housing
Measurements
485(L)X272(W)X93mm(H)
Product Weight 3150g
Media Failure Interval 30，000 Hours
Warranty One year warranty, lifetime maintenance
10.0 Common Problems and Solutions
1. What to do if the VAX matrix front panel keys switching not responsive?
Answer: The VAX matrix front panel keys employ scanning testing and require longer response
time. Press the keys for 2 seconds and then release. This way, key switching will be
responsive in operation.
2. What to do if matrix does not display or color display is abnormal after hot plug?
Answer: Switching of the matrix system goes through the IC chips. If the voltage difference
between the input signal equipment and the matrix equipment is too large, hot plug
could easily cause damage to the IC chips. Please turn off power to the system before
plugging or unplugging.
3. What to do if ghosting happens when VGA signals output to display?
Answer: Ghosting is often caused either by the projector, inferior cable quality or long
transmission distance. You are advised to adjust the projector or replace with better
quality cable.
4. What to do if loss of color reproduction happens or no video signal output?
Answer: Please check if connectors at both ends of the VGA signal cable are correctly
connected.
