This step requires two people

to lift and position grill head

onto cart.

Carefully lower the grill

head onto the cart, aligning slots at

bottom of grill head with posts on

cart side panels. Make sure the

regulator hose is hanging inside

the cart. Grill head must face open

side of cart.

Regulator hose

Grill head

Connect Adapter wire harness and Light wire harness.

Adapter

Light wire harness

Adapter wire harness

Lower back panel

(Inside)
