On back of drawer, secure back panel using four #8x3/8” self-tapping screws on each side.

#8x3/8” self-tapping

Back panel

screw

1/4-20x1/2”

screw

7mm lock

washer

Insert hinge pin on bottom of doors into hole in bottom shelf. Press upper hinge pin in top of door, align hinge hole under

drawer front bracket-L, and release hinge pin, shown B.

Hinge pin

on bottom

of door

PRESS

Front door

panel

Drawer

front bracket-L

Attach door handle to front door panel using two 1/4-20x1/2” screw, 7mm lock washer, shown A.

A

Front door panel

Door handle

B
