Char-Broil 463269411 User Manual
Page 13
PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
13
Key Qty Description
A
1
OUTER TOP LID INSERT
B
1
INNER TOP LID INSERT
C
2
RUBBER BUMPER, RECTANGLE, F/
TOP LID
D
4
RUBBER BUMPER, ROUND
E
1
LOGO PLATE
F
1
HANDLE F/ TOP LID
G
1
HARDWARE F/ TOP LID ASSEMBLY
H
1
WARMING RACK
I
3
COOKING GRATE, MAIN
J
3
EMITTER, F/ COOKING GRATE
K
4
FLAME TAMER
L
1
FIREBOX
M
1
CONTROL PANEL, TOP
N
1
CONTROL PANEL, BOTTOM
O
4
PIN, F/ DOOR
P
1
HEAT SHIELD, F/ CONTROL PANEL
Q
1
HEAT SHIELD, F/ HOSE GUARD
R
1
HOSE VALVE REGULATOR
ASSEMBLY
S
4
BEZEL, F/ CONTROL KNOB
T
4
CONTROL KNOB
U
4
TEMPERATURE GAUGE, UFC
MOUNTED
V
4
MAIN BURNER
W
2
ELECTRODE, F/ MAIN BURNER,
900MM WIRE
X
2
ELECTRODE, F/ MAIN BURNER,
600MM WIRE
Y
3
CARRYOVER TUBE
Z
1
IGNITER SWITCH MODULE
AA
1
LIGHT SWITCH
BB
1
HALOGEN LIGHT ASSEMBLY
CC
2
COVER BOX, F/ LIGHT
DD
3
HOSE CLIPS
EE
1
LEFT SIDE CART PANEL
FF
1
RIGHT SIDE CART PANEL
GG
6
MAGNET ASSEMBLY
HH
1
BOTTOM SHELF
II
1
TANK SCREW, F/ BOTTOM SHELF
JJ
3
DOOR MAGNET ASSEMBLY
KK
2
CASTER, LOCKING
LL
6
CASTER, FIXED
MM
1
CART LOWER BACK PANEL
NN
1
GROMMET, F/ REGULATOR HOLE
OO
1
CART UPPER BACK PANEL
Key Qty Description
PP
1
HEAT SHIELD F/ TANK
1
TANK PARTITION
RR
1
MATCH HOLDER
SS
1
GREASE TRAY
TT
1
FRONT BRACE
UU
1
LEFT DOOR, NO HANDLE
VV
2
DOOR HANDLE
WW
1
RIGHT DOOR, NO HANDLE
XX
1
HEAT SHIELD, F/ SWITCH MODULE
YY
1
ELECTRONIC IGNITION MODULE
ZZ
1
CAP F/ EI MODULE
AAA
1
12 VOLT ADAPTER
BBB
2
BOTTOM SHELF, F/ CABINET
CCC
4
CASTER, LOCKING, F/ CABINET
DDD
1
LEFT SIDE PANEL, F/ LEFT CABINET
EEE
1
RIGHT SIDE PANEL, F/ LEFT CABINET
FFF
2
DRAWER END CAP, LEFT
GGG
2
DRAWER END CAP, RIGHT
HHH
2
FRONT DOOR BRACE, F/ CABINET
III
1
TOP SHELF, F/ LEFT CABINET
JJJ
1
INNER SHELF, F/ LEFT CABINET
KKK
2
BACK PANEL, F/ CABINET
LLL
1
DRAWER FRONT
MMM
3
CABINET HANDLE
NNN
1
DRAWER FRAME, F/ LEFT CABINET
OOO
2
CABINET DOOR, NO HANDLE
PPP
1
LEFT SIDE PANEL, F/ RIGHT CABINET
QQQ
1
RIGHT SIDE PANEL, F/ RIGHT
CABINET
RRR
1
TOP SHELF, F/ RIGHT CABINET
SSS
1
SWING DRAWER, F/ RIGHT CABINET
TTT
2
HINGE, F/ SWING DRAWER
Key Qty Description
…
1
CASTER PIN
…
1
HARDWARE PACK
…
1
ASSEMBLY MANUAL, ENGLISH
…
1
ASSEMBLY MANUAL, SPANISH
…
1
CLEANING TOOL
NOT Pictured
