Page 2
Maximum cable length for compatible controllers and cameras
For repeater connection, maximum of 2-step connection is possible. For con-
nection-possible number of steps and maximum cable length, see the chart
below.
For extension, do not allow the cable length and connection steps to go
beyond their maximum limits.
*1 When reading parts less than 350 lines, the number of maximum connection
steps is 1 and the maximum cable length is 34m.
*2 When reading parts less than 1000 lines, the number of maximum connection
steps is 1 and the maximum cable length is 20m.
*3 The controllers and camera expansion units shipped after September 14,
2009 are compatible with the repeater connection.
Power consumption list for controllers when the repeater is
connected
The rated power consumption increases when the repeater is connected.
Specifications
Outer Dimensions
Controller*3
Camera
Compatible
repeater
Cable length specification
Maximum number of
connection steps
Maximum cable
length
CV-3001/
CV-3501
CV-035C/M
CA-CNX10U
2 steps/1 step (*1)
51m/34m (*1)
CV-S035C/M
1 step
20m
CV-200C/M
2 steps
30m
CV-S200C/M
2 steps/1 step (*2)
30m/20m (*2)
CV-5000/
CV-5500/
CV-5700/
CV-X100/
CV-X150/
CV-X170
CV-035C/M
CA-CNX10U
2 steps/1 step (*1)
51m/34m (*1)
CV-S035C/M
1 step
20m
CV-200C/M
2 steps
30m
CV-S200C/M
2 steps/1 step (*2)
30m/20m (*2)
CV-H035C/M
CA-CHX10U
2 steps
30m
CV-H100C/M
2 steps
30m
CV-H200C/M
1 step
20m
CV-H500C/M
1 step
20m
XG-7000/
XG-7500/
XG-7700/
XG-8000/
XG-8500/
XG-8700/
XG-8800/
XG-8500L/
XG-8700L/
XG-8800L
XG-035C/M
CA-CNX10U
2 steps/1 step (*1)
51m/34m (*1)
XG-S035C/M
1 step
20m
XG-200C/M
2 steps
30m
XG-S200C/M
2 steps/1 step (*2)
30m/20m (*2)
XG-H035C/M
CA-CHX10U
2 steps
30m
XG-H100C/M
2 steps
30m
XG-H200C/M
1 step
20m
XG-H500C/M
1 step
20m
XG-8500L/
XG-8700L/
XG-8800L
XG-HL02M
CA-CHX10U
2 steps
30m
XG-HL04M
2 steps
30m
XG-HL08M
2 steps
30m
Controller type
Connected
camera
Power consumption when the repeater is connected
(When not connected)
CV-3001
2
1.6(1.4)A
CV-3501
2
2.1(1.8)A
4
3.4(2.8)A
CV-5001
2
2.5(2.2)A
CV-5501
2
2.7(2.4)A
4
3.8(3.2)A
CV-5701
2
2.7(2.4)A
4
3.8(3.2)A
XG-7000
2
2.5(2.2)A
4
3.4(2.8)A
XG-7500
2
2.7(2.4)A
4
3.8(3.2)A
XG-7700
2
2.7(2.4)A
4
3.8(3.2)A
XG-8000
2
3.0(2.9)A
4
3.8(3.5)A
XG-8500/8700
2
3.2(3.0)A
4
4.1(3.8)A
XG-8800
2
3.2(3.0)A
4
4.1(3.8)A
6
4.9(4.4)A
8
5.8(5.0)A
XG-8500L
1
2.6(2.4)A
2
2.8(2.5)A
XG-8700L
1
2.8(2.7)A
2
3.3(3.0)A
XG-8800L
1
2.5(2.4)A
2
2.7(2.5)A
3
3.0(2.7)A
4
3.0(2.8)A
CV-X100
2
2.2(1.9)A
CV-X150
2
2.8(2.5)A
4
3.4(2.8)A
CV-X170
2
3.1(2.8)A
4
3.7(3.1)A
Product name
Repeater for camera cable extension
(For normal camera)
Repeater for camera cable extension
(For high-speed camera)
Model
CA-CNX10U
CA-CHX10U
Connection camera
CV/XG-035C/M
CV/XG-S035C/M
CV/XG-200C/M
CV/XG-S200C/M
CV/XG-H035C/M
CV/XG-H100C/M
CV/XG-H200C/M
CV/XG-H500C/M
XG-HL02/04/08M
Transfer system
Digital serial transfer
Environment
resistance
Ambient
temperature
When connecting CV/XG-035C/M:
0 to +50
°C
0 to +40
°C
When connecting other cameras:
0 to + 40
°C
Ambient
humidity
35 to 85
%RH (No condensation)
Dimensions
112.6 (W)
× 26 (D) × 21 (H)
Weight
Approx. 60g
Ø6.1
CA-CN3LX/CN10LX/CN17LX
Ø12.5
43
L
31.2
38
Ø7.6
53.9
L
53.9
Ш14
Ш12.5
Ш14
Ш12.5
Ш7.2
Ш12.5
Ш12.5
43
L
43
CA-CNX10U/CHX10U
CA-CNX10U/CHX10U
Ø14
CA-CN3X/CN10X/CN17X
CA-CH3X/CH10X
CA-CN3RX/CN10RX/CN17RX
CA-CH10RX
(85)
(85)
(213)
When the cable is attached
Units: mm
Units: mm
Units: mm
Units: mm
Units: mm
2xØ3.6
Through-hole
19
26
3.5
112.6
105
98
3.5
21
6
11
6
11
.5
Model name
Cable length (L)
Weight
CA-CN3X
3m
Approx. 200g
CA-CN10X
10m
Approx. 600g
CA-CN17X
17m
Approx. 990g
CA-CH3X
3m
Approx. 270g
CA-CH10X
10m
Approx. 820g
CA-CN3RX
3m
Approx. 190g
CA-CN10RX
10m
Approx. 540g
CA-CN17RX
17m
Approx. 900g
CA-CH10RX
10m
Approx. 740g
CA-CN3LX
3m
Approx. 210g
CA-CN10LX
10m
Approx. 610g
CA-CN17LX
17m
Approx. 1000g
