Standard Paragraph Designation Value
EN 60730 2.2.15 Purpose of control unit: Motor protection device
6.2.6 Type of controlled load: pilot load
6.4 Reset characteristic: not automatic: type 3BH
automatic: type 3C
Software class A
Device protection class
Relevant standards
Fault memory:
The Bock BCM 2000 (v1.4) software provides the possibility of exporting the complete fault
memory of the BCM 2000 to a text file thus making a backup of it.
Procedure for backing up the fault memory:
1. A voltage of 230 V must be applied between L1 and N of the BCM 2000.
2. The BCM 2000 must be connected to a PC using the special cable.
3. Start the BCM 2000 software and wait until the fault report is read out.
4. On the “Diagnostics” screen, there is the “Export” button next to the “Retrieve” button which
makes a new readout of the BCM 2000 possible when clicked.
5. The BCM 2000 software creates a text file (“Export File”) when the “Export” button is clicked.
6. Select the destination where the text file should be saved. Input filename and confirm with
“Save”. The name of the backup file should contain the machine number, type and date.
Example: AN022334A014-HGX8-2830-4S-01012006.txt
