8. Module Overview
System A-100
DOEPFER
DOEPFER
DOEPFER
DOEPFER
29
Module Width
Curr.
Curr.@5V Description
A-186
4
0
-
Gate / Trigger Combiner
7 inputs that are "OR-wired" to the output, mainly for combination of gate/trigger signals
A-187-1
?
?
-
Voltage Controlled DSP Effects Module
(still under development)
DSP based effects module with four voltage controlled parameters
A-188-1
14
80
-
BBD Module
BBD module, available with 6 different BBD circuits from 128 to 4096 stages
A-188-2
30
120
-
Tapped BBD Module
BBD module with 6 taps, single outputs and two (stereo) submixers
A-189-1
8
60
-
Voltage Controlled Bit Modifier
16 different voltage controlled bit modification effects (e.g. bit cruncher) with VC sample rate
A-190-1
10
10
•
/ 50
MIDI-CV/SYNC-Interface
MIDI-to-CV and sync interface
A-190-2
6
30
-
MIDI-CV-Interface
low cost MIDI-to-CV interface with manual glide control and four CV outputs
A-190-3
?
?
-
Polyphonic MIDI/USB-CV-Interface
(still under development)
Midi-CV interface with four CV and gate outputs, different monophonic/polyphonic modes
A-191
12
30
•
/ 50
MIDI-CV-Interface/Shepard Generator
(module no longer available)16-fold
MIDI-to-CV interface and Shepard generator
A-192-1
12
100
-
Voltage-to-MIDI Interface
16 CV inputs (0...+5V) are converted into MIDI control change messages
A-192-2
?
?
-
CV/Gate-to-Midi/USB-Interface
(still under development)
converts CV/Gate signals into Midi note messages
A-195-1
?
?
-
Pitch-to-CV/Gate/Midi/USB-Interface
(still under development)
converts clean monophonic audio signals into CV/Gate/Midi/UBS
