DOEPFER DOEPFER DOEPFER DOEPFER System A-100 8. Module Overview
24
Module Width Curr. Curr.@5V Description
A-130 8 20 -
VCA - Voltage Controlled Amplifier
voltage controlled amplifier with linear response
A-131 8 20 -
VCA - Voltage Controlled Amplifier
voltage controlled amplifier with exponential response
A-132-1 4 20 -
Dual Low Cost VCA
two simple voltage controlled amplifier with linear response
A-132-2 8 30 -
Quad VCA
four VCAs with independent inputs and outputs, common loudness/level control
A-132-3 8 30 -
Dual linear/exponential VCA
two separate VCAs with selectable control scale (switch, linear or exponential)
A-133 8 30 -
Dual Voltage Controlled Polarizer
two special VCAs with positive and negative (=inverting) amplification
A-134-1 8 40 -
VC PAN - Voltage Controlled Panning / Crossfader
module for voltage controlled panning or crossfading
A-134-2 4 20 -
Dual VC Crossfader
Two separate voltage controlled crossfaders
A-135-1 22 30 -
VC MIX - Voltage Controlled Mixer
4 separate VCAs with common output
A-135-2 ? ? -
VCF/VCA/Panning subsystem (still under development)
subsystem with VCFs with VCQ, VCAs and VC panning units with common stereo output
A-136 8 30 -
Distortion/Waveshaper
distortion and wave-shaping / wave-modifying module with extensive control possib.
A-137-1 14 40 -
Voltage Controlled Wave-Multiplier I
waveform multiplier with 4 VC parameters: Multiples, Harmonics, Folding, Symmetry
A-137-2 14 30 -
Voltage Controlled Wave-Multiplier II
makes one sawtooth VCO sound like five VCOs (four VC algorithmic phase shifters)
