8. Module Overview
System A-100
DOEPFER
DOEPFER
DOEPFER
DOEPFER
23
Module Width
Curr.
Curr.@5V
Description
A-121
12
30
-
VCF 2 - 12 dB Multimode Filter
voltage controlled 12 dB multimode filter (low pass, high pass, band pass, notch)
A-122
8
20
-
VCF 3 - 24 dB Low Pass 2
(combined manual A-105/A-122)
voltage controlled 24 dB low pass (with CEM3320, Oberheim type)
A-123
8
20
-
VCF 4 - 24 dB High Pass
(module no longer available)voltage controlled 24 dB high
pass
A-124
8
30
-
VCF 5 - 12 dB Wasp Multimode Filter
reproduction of the strange multimode filter used in the EDP Wasp Synthesizer
A-125
8
20
-
VCP - Voltage Controlled Phaser
voltage controlled FET based phase shifter with resonance
A-126
8
80
-
VCFS - Voltage Controlled Frequency Shifter
voltage controlled analog frequency shifter
A-127
28
100
-
VCRF - Triple Voltage Controlled Resonance Filter
3 independent voltage controlled band pass filters with 3 LFOs
A-128
20
20
-
Fixed Filter Bank
filter bank with 15 band filters
A-129-1
20
100
-
Vocoder Analysis Section
Analysis section of the modular vocoder
A-129-2
12
80
-
Vocoder Synthesis Section
synthesis section of the modular vocoder
A-129-3
16
40
-
Vocoder Slew Limiter
universal 5-fold voltage controlled slew limiter/attenuator/offset generator
A-129-4
8
30
-
SLC - Slew Limiter Controller
controller module for slew limiter function of A-129/3
A-129-5
8
30
-
VUV - Voiced / Unvoiced Detector
module for recognition of "voiced/unvoiced" speech
