DOEPFER DOEPFER DOEPFER DOEPFER System A-100 8. Module Overview
28
Module Width Curr. Curr.@5V Description
A-175 4 20 -
Dual Voltage Inverter
two independent analog voltage inverter with displays
A-176 8 20 -
CVS - Control Voltage Source
3 manual adjustable control voltages
A-177-1 8 30 -
External Foot Controller I (module no longer available)
interface module for 2 foot controlers and one double foot switch
A-177-4 4 ~ 20 -
External Foot Controller II (still under development)
simple interface module for one foot controller and one double foot switch
A-178 8 60 -
Theremin Control Voltage Source
variable voltage/gate source controlled by hand movement
A-179 8 60 -
Light Controled Voltage Source (module no longer available)
variable voltage/gate source controlled by light intensity
A-180 4 - -
Multiples I
8-fold multi connector (may be splitted into two 4-fold multi connectors)
A-181 4 - -
Multiples II
two multiples with 3.5 mm and 1/4“ mono and stereo sockets
A-182 6 0 -
Switched Multiple
eight sockets that can be switched to one of two busses or turned off
A-183-1 4 0 -
Dual Attenuator (still under development)
two simple passive attenuators
A-183-2 4 ~ 20 -
Offset Generator + Attenuator/Polarizer (still under development)
generates an offset voltage that is added to an attenuated or inverted input voltage
A-183-3 4 ~ 20 -
Amplifier (still under development)
simple DC coupled amplifier with adjustable gain, max. gain can be swithed to 1,2 or 4
A-185-1 4 30 -
Bus Access Module
module for access to bus signals CV and gate
A-185-2 6 30 -
Precision Adder / Bus Access
high precision CV adder (0,1%) with four inputs and optional access to bus CV
