Maintenance
4
Spark plug removal
1. Remove the engine cover by:
1a. Remove the screws that hold the cover in
place.
NOTE: There are eight screws for the engine
cover, four that go into the engine block casting
and three that go into the blower housing and
one into the fuel tank bracket. Make sure you put
the machine threaded screws into the casting
and the plastic threaded screws into the blower
housing and fuel tank bracket. See Figure 2.2.
1b. Lift the cover up and away, sliding it out from
in between the engine block and the fuel
tank bracket. See Figure 2.3.
2. Disconnect the spark plug wire. See Figure 2.4.
3. Remove the spark plug using a 5/8” spark plug
socket. See Figure 2.5.
4. Gap a new plug at .025” (.6 mm).
5. Install the spark plug and tighten to a torque of
120 in. lbs.(12 -15 Nm).
6. Follow steps 1 and 2 in reverse order.
7. Test run the blower in a safe area before return-
ing to service.
Figure 2.2
Plastic threaded
screw
Machine threaded
screw
Figure 2.3
Slide cover out from in between
the engine and the fuel tank bracket
Figure 2.4
Disconnect the spark plug wire
Figure 2.5
Remove using
a 5/8” spark plug
socket
