IR Speed Dome Operating Manual
42
•PATTERN TOUR
The dome supports 4 pattern tours and each pattern
cover at most 10 Minutes of 500 commands. Please check
the following steps to set up a pattern.
1) PATTERN NO.: Move the cursor here and press IRIS OPEN to
enter the setup of Pattern Number. Move the joystick to select a
pattern number (14) and press IRIS OPEN to confirm.
2) TITLE: Move the cursor here and press IRIS OPEN ro
enter the setup of Pattern Title .Check the detailed
above in DOME TITLE settings.
3) : Move the cursor here and press IRIS OPEN to
enter.Move the dome up/down/left/right,make the zoom
in/out and press IRIS OPEN to save the pattern tour.
4) START: Move the cursor here and press IRIS OPEN to start the
current pattern tour.
5)
DELETE: Move the cursor here and press IRIS OPEN to delete
the current pattern tour.
MAIN MENU
LANGUAGE :ENGLISH
RESTART
FACTORY DEFAULTS
HELP
EXIT
MOTION
BACK EXIT
PATTERN
PATTERN NO. :1
TITLE :PATTERN 1
START
DELETE
BACK EXIT
