IR Speed Dome Operating Manual
15
main OSD menu (or call preset No.1 two times continuously within two
seconds)
Control the joystick to move the cursor around the menu
Press “Iris Open” to enter the menu for selections
Move the joystick up and down to select the item
Press “Iris Open” to confirm the selection
Press “Iris Close” to cancel the selection
*Note: If your controller does not have a joystick, use the up or down key.
•
OSD Menu Description
SYETEM INFORMATION
DOME ID :1234567890
ADRESS:001
BAUDRATE:2400
PROTOCOL:PELCO-D
TEMPERATURE:31℃
VOLTAGE:12.0V
ALARM:000000 00
BACK
EXIT
IRIS
OPEN
IRIS
OPEN
IRIS
OPEN
