Operator: The name or initials of the individual that performs the assay can be entered in the operator
input field prior to starting the analysis.
Current Run and Next Run: The lower right part of the main window holds the main results of the active
image analysis (from the last run or the file that is selected in the browse list). Detailed results are available
by left-clicking on the result tab page in the upper left corner on the main window. After an analysis, the
input fields will display the entries for the previous analysis and the input fields will be enabled for entering
new entries for the Next Run.
This button starts the analysis according to the selected application. During the first part of the
analysis an ‘Analysis in Progress’ image will be displayed.
Return to ‘acquisition mode’ to run a new analysis, when the instrument is connected.
This button inserts or ejects the slide tray.
This button allows the user to export the results for the shown files as a CSV file.
Menu Line
File -> Import Package: Imports files into the NucleoView™ NC-250™ software. This will typically be a zip-file
containing multiple license, protocol and documentation files, or individual *.cmsx, *.cmsu and *.pdf files.
File -> Export Data: Opens a window where the acquired data from an analysis can be exported in ACS or
FCS file formats.
File -> Exit: Shuts down the program.
Tools -> Plot Manager: Opens a new Plot Manager window which can be used for advanced post processing
of CM-files.
Tools -> Protocol Adaptation Wizard: Opens the Protocol Adaptation Wizard which is used to create user
adapted versions of protocols.
Tools -> Report Generator: Opens the File Browser and the Report Generator which are used to create
collected results in a table or for data export of one or several data files.
Tools -> Options: Opens the options dialog where the result folder can be changed, user login settings
enabled, 21 CFR Part 11 can be turned on or off (See details in 21 CFR Part 11 section) and image
compression options can be set.
