– 10 –
6. Press the RECALL key. The display blinks, showing the
maximum peak value of the measuring period and the
indicated symbol.
7. Press the RECALL key. The display blinks, showing the
maximum peak value of the measuring period and the
indicated symbol.
8. Press the RECALL key. The tension meter switches back to
the measuring mode. The display shows MEM and the current
reading.
The tension meter is ready for a new measuring period.
6.3 Clearing Tension Values Stored In Memory
If values are stored in the tension meter memory, the DISPLAY
hows with the MEM indicator.
1. To clear the memory, simultaneously press the MEM and
RECALL keys. The MEM indicator disappears
and all values stored inmemory are deleted.
6.4 Memory Function HOLD
When the tension meter memory is empty, you can retain the last reading on the Display
by using the memory function HOLD.
To retain the last reading:
Press the RECALL / HOLD key once for about 1 second. The
Display shows the last readingand the “:” colon symbol.
To switch back to measuring mode:
Press the RECALL / HOLD key once for about 1 second.The tension meter switches
back to measuring mode.
6.5 Error Messages
1. The Display shows EEE. The upper limit of the tension range was
exceeded by more than 10%. Reduce the line tension.
OR
AUTO ZERO is no longer possible.
Recalibrate the instrument following the directions in Sec. 8.0.
26
D cN
19
D cN
3
D cN MEM
3
D cN MEM
3
D cN
2:2.8
D cN
EEE
D cN
MEM
MEM
– 11 –
2. The Display shows -E.E. The lower limit of the tension range
has fallen below by more than 10%.
Properly insert the process material.
OR
AUTO ZERO is no longer possible.
Recalibrate the instrument following the directions inSec. 8.0.
–EE
D cN
