7
13. LIMIT LED: Indicates one of the manual limit switches has been tripped.
14. OVERLOAD LED: Indicates that the force gauge has been overloaded.
15. ALARM LED: Indicates test stand’s motor has been overloaded.
16. RST/ : Changes the increment point upward.
17. TIME/ : Changes digit position when programming force limits, also changes delay be
tween
cycles.
18. SET: Stores a program cycle to a value that the user selects using RST/ and TIME/ .
19. MODE: Selects mode of operation: Manual, Jog, Single, Continuous or Program.
20. Operation Display: Informs user of current mode of operation.
21. PULL: Test stand moves in the left movement or upward direction.
22. STOP: Stops test stand movement.
23. PUSH: Test stand moves in a tight movement or downward direction.
24. PROG START: Start the program.
25. Emergency Stop (located on the top of the test stand.
