TESC Operator's Manual, Rev 1.0
11
CANNON®
Getting Started
Figure 3 — Brookfield® DV2T connections
Figure 4 — TESC connections
RTD probe
RTD probe
socket
MAINS AC
power input
(base)
MAINS AC
pass-through
(unswitched)
MAINS AC
power input
On/off
USB B
USB A
