Speaker Configuration
“Speaker Configuration” applies only to the HDMI
Audio Output and LFE Mixdown mode. The other
digital outputs and normal operation of the Analog
Audio Outputs are unaffected by these settings.
For proper performance of the HDMI
Audio Output and LFE Mixdown
mode, it is critical that the settings be
adjusted exactly as they were
pre-configured at the factory. If they
should ever be changed, be sure to
revert them to their original settings as
explained below.
Enter the “Speaker Configuration” menu. There will
be a picture of a listening room with speakers. At
the bottom of the yellow floor, the
Down Mix Mode
is indicated. This should be 7.1Ch.
If it is not 7.1Ch, use the “Right”/“Left” arrow
buttons to highlight the Down mix sign behind the
couch. Press “Enter”, use the “Up”/“Down” arrow
buttons to select
7.1Ch and then press the “Left”
arrow button to return to the picture of the
listening room.
Next, select a speaker, press “Enter” and adjust the
Size to Large, the Distance to 0 ft, and the Trim to
0.0 dB. Select the Next Speaker, and apply the
same settings to all speakers except the
Subwoofer.
For the Subwoofer (SW), select the Size as On, the
Distance as 0 ft, and the Trim as 5.0 dB.
