Audio Processing
Speaker Configuration
(These settings affect the HDMI Audio Output and LFE
Mixdown. They must be set correctly for proper operation.)
FL
Size [ Small | Large ]
Distance [ 0–12–60 ] (Same as FR.)
Trim [ -10.0–0.0–10.0 ]
SW
Size [ On | Off ]
Distance [ 0–12–60 ]
Trim [ -10.0–0.0–5.0–10.0 ]
C
Size [ Small | Large | Off ]
Distance [ 0–12–60 ]
Trim [ -10.0–0.0–10.0 ]
FR
Size [ Small | Large ]
Distance [ 0–12–60 ] (Same as FL.)
Trim [ -10.0–0.0–10.0 ]
SR
Size [ Small | Large | Off ]
Distance [ 0–12–60 ] (Same as SL.)
Trim [ -10.0–0.0–10.0 ]
SBR
Size [ Small | Large | Off ]
Distance [ 0–12–60 ] (Same as SBL.)
Trim [ -10.0–0.0–10.0 ]
SBL
Size [ Small | Large | Off ]
Distance [ 0–12–60 ] (Same as SBR.)
Trim [ -10.0–0.0–10.0 ]
SL
Size [ Small | Large | Off ]
Distance [ 0–12–60 ] (Same as SR.)
Trim [ -10.0–0.0–10.0 ]
Down Mix Mode [ LT/RT | Stereo | 5.1ch | 7.1ch ]
