R ECORD T IME L IMIT
• NONE
• 30
SEC
• 1
MIN
• 5
MIN
• 30
MIN
• 60
MIN
Enhances the management of available Disk space of DigiCart/EX and accelerates entry to the Record
Ready condition when set to smaller values. Furthermore, you can start a recording and walk away
knowing that after the specified time limit (setting +5%), the unit will stop recording.
S ET A UX P ROTOCOL
• ES-BUS
• PERIPHERAL-BUS
(GV)
• PERIPHERAL-BUS
(SONY)
Defines the serial protocol for the AUX serial port on the rear panel. See Appendix B for Serial
Protocol documentation.
S ET C ONTRAST
• 0 to 100
Adjusts the LCD contrast. Select a value that works best for your viewing angle and lighting
conditions.
S ET H EADPHONE L EVEL
• 0 to 64 (1 db per step)
Adjusts the volume for the ¼” headphone jack on the front panel. Select a value.
The Headphone level can also be set by pressing the Setup button during playback. Press Setup
again to keep the new setting and return to the normal playback display.
S ET I NPUT M ONITOR
• OFF
• ON
or DISABLED BY D-NET
Allows you to monitor audio that has been processed through the digital audio circuitry.
Digital monitoring cannot be accomplished if the D-NET receiver is enabled. The message,
“Disabled by D-Net” will appear to advise you that the input monitor cannot be turned on.
NOTE: DigiCart/EX provides "pass through" A/D - D/A audio when the REC button is pressed.
Therefore, most operations may be accomplished with the INPUT MONITOR: OFF.
S ET IP A DDRESS
• AUTOMATIC
• 192.168.1.16 – 31, 192.168.2.16-31
DigiCart/EX can automatically set its IP address using network DHCP services. If running on a
network without DCHP service, the IP address can be set manually. One of thirty-two addresses can
