Chapter 4
Setup and Utility Menus
Menu Navigation
The SETUP menu defines the operational behavior of the DigiCart/EX. Setup options are displayed
alphabetically in a rotating list.
• Press
SETUP.
Rotate the Selection Knob to view the options.
• Use the navigation arrow buttons to select the available settings for the selected option.
• Setup parameters are stored on DigiCart’s internal hard disk. Settings do not have to be
confirmed, changes take place immediately.
• Press
EXIT
.
The UTILITY menu is used to access special operations such as Assign Hot Keys, Copy, Delete,
Rename, , and disk format operations. Utility operations are displayed alphabetically in a rotating
list.
• Some Utility operations are dependent on the selection of DRIVE, DIRECTORY or FILE.
Select the Drive, Directory or Cut you want to operate on before entering the Utility
menu.
• Press
UTILITY.
Rotate the Selection Knob to view the options.
• Press the
ENTER
button to initiate the chosen operation.
• Press
UTILITY
or
EXIT
to exit the menu.
The Utility menu selection is stored in temporary memory. If you need to repeat a copy operation,
that option will be displayed first upon subsequent presses of the
UTILITY
button. The button
illuminates while in Utility mode.
Setup Menu Features
D-N ET R ECEIVER
Setting this parameter ON configures the digital I/O ports to allow receiving D-Net file transfers from
other DigiCarts. See Appendix D on page 70 for a complete discussion of D-NET. The following four
parameters appear only if D-NET Receiver is ON:
D-NET R ECEIVER I NPUT
- Select the digital input to be used to receive D-NET. See page 83.
- Select where received files are placed. See page 83.
D-NET R ECEIVER D IR
- Give this DigiCart/EX a name to allow addressed transfers. See page 83.
D-NET R ECEIVER N AME
- Allow this DigiCart/EX to pass transfers through its digital outputs to 1 or
more other units. See page 83.
D-NET R ECEIVER E CHO
