NV-H65A, EA, BA
Power Source:
Power Consumption:
Vìdeo Recording System:
Tape Bpeed:
Tape Format:
Record/Playback Time:
FF/REWTime:
VIDEO
Television System:
Modulation System:
Input Level:
Output Level:
AUDIO
Input Level:
Output Level:
Audio Track:
Video Horizontal Resolution:
Signal-to-Noise Ratio:
Dynamic Range:
Audio Frequency Response:
Wow and flutter:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
Standard Accessories:
NV-H65A: 240 V AC 50-60 Hz
NV-H65EA: 230 V AC 50-60 Hz
NV-H65BA: 110-240 V (AUTO VOLTAGE) AC 50-60 Hz
NV-H65A, EA: Approx. 28 watts
NV-H65BA:
Approx. 27 watts
2 rotary heads, helical scanning system
23.39 mm/sec.
fflStape
240 min. with NV-E240
Less than 5.5 min. with NV-E180
CCIR: 625 lines, 50 fields, PAL colour signal
Luminance: FM azimuth recording
Colour signal: converted subcarrier phase shift recording
VIDEO IN (BNC):
I.OVp-p,
VIDEO OUT (BNC); 1.0 Vp-p,
RF Modulated; NV-H65A: VHF channel 0 or 1,
NV-H65EA: VHF channel 2 or 3,
NV-H65BA: UHF channel 36 (±4),
AUDIO IN (PHONO); -10dB,
AUDIO OUT (PHONO); -8dB.
HEADPHONES; -30 dB.
1 track (Normal-mono only), 2 channels (Hi-Fi sound-stereo)
Colour: more than 240 lines
Video; more than 43 dB
Audio; more than 90 dB (Hi-Fi audio track)
20 Hz-20 kHz (Hi-Fi audio track)
0.005% Wrms/Hi-Fi
5“C-40°C
35%-80%
6.0 kg
430 (W)x82 (H)x352 (D) mm
1 pc. DIN-DIN coaxial cable
1 pc. Programmable remote controller (ln|fra-red)
2 pcs. Stereo type PHONO cable
1 pc. AC Mains Lead
75 ohm, unbalanr
75 ohm, unbalant
75 ohm, unbalant
75 ohm. unbalant
75 ohm, unbalan
more than 50 kohm, unbalan
less than 1 kohm, unbalan
8 ohm
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
