ToHIWl MTS Broadcast/VHS Hi-Fi Stereo System
[^3 Check list before you begin.
D The VCR is connected to a stereo TV, or a mono TV and an external stereo amp or receiver with speakers.
Q The VCR and other components are plugged in and turned on.
Connections
to Make
When recording, you may monitor in
stereo, by connecting the VCR to either
a stereo TV, or a mono sound TV with
an external stereo amp and speakers.
!5
O ©
0 0©
O © ©
® © ©
DISPLAY
Equipped with
dbx*
-TV Noise
Reduction for true MTS reproduction,
dbx*
-TV Noise Reduction is
required for good stereo separation
and audio fidelity.
dbx*
is a
registered trademark, and is licensed
by
dbx*
Technology Licensing.
Receivable Broadcast Types
The following are possible audio broadcast types and on-screen displays.
The signal being received is indicated with an “(ct” mark while the selected audio
mode is indicated with an arrow.
Press DISPLAY to display the broadcast signal
currently being received.
MTS Stereo and SAP broadcast
Multi-channel Television Sound Stereo
(main language) and Secondary Audio
Program (sub language) broadcasts are
being received simultaneously. Select
STEREO or SAP audio mode.
AfrS Stereo broad4:a8t
Multi-channel Television Sound Stereo
broadcast. Select STEREO audio mode.
• If a stereo broadcast is weak and the display
flickers, you may want to select the MONO
audio nxxje for better results.
SAP broadcast
Secondary Audio Program (sub language)
broadcast. Select SAP audio mode for the
sub language.
MONO broadcast
Normal monaural sound broadcast.
STOP 12:00AM ABC
( >:00:00
• STERECH
• SAP
MONO
SP
STOP 12:00AM ABC
0:00:00
• STEREOS SP
SAP
MONO
STOP 12:00AM ABC
0 : 00:00
STEREO SP
• SAP
MONO
STOP 12:O0AM ABC
0 : 00:00
STEREO SP
SAP
MONO
■*
