Specifications
GENERAL
VIDEO
(Digital video)
(Line OUT)
(Output connectors)
AUDIO
(Digital audio)
(Output connectors)
DISPLAY TUBE
Power supply;
Power consumption: 120 V A C , SOHz-eOHz
37 W
Ambient operating temperature; 4rFto104°F (5X to 40°C)
Ambient operating humidity: 35% to 85% (no condensation)
Weight: 15.4 ibs. (7.0 kg)
Dimensions (W x H x D): 8-7/16~x 5-1/4"x 15-7/16"(214 x 132 x 391 mm)
Format: DVCPRO
T racks: Digital video
Time code: Piayback in sub-code area
Digital audio: 2 channeis
Cue track; 1 track
Control (CTL): 1 track
Tape speed: 33.820 mm/sec.
Playback time: 123 minutes (using AJ-P123LP tape)
63 minutes (using AJ-P63MP tape)
Tape used: 1/4" thin magnetic layer metal tape
FF/REW time: Within 3.5 min. (using AJ-P123LP tape)
Sampling frequency: 13.5 MHz for Y; 3.375 MHz for P b /P r
Quantizing; 8 bits
Error correction: Reed-Solomon product code
Video band; 30 Hz to 4.5 MHz (0 ±2.0 dB) for Y
Y/C delay: Less than 20ns
K factor: Less than 3%
Analog composit output: BNC X 1; 1.0 V p - p , 75 Q
Monitor output: Phono X 1; 1.0 Vp-p, 75 ii (superimpose on/off)
S-VIDEO: 4P X 1; Y: 1.0 Vp-p, 75 Q
C: 0.286 Vp-p, 75 Cl (burst level)
Sampling frequency: 48 kHz
Quantizing: 16 bits
Frequency response: 20 Hz to 20 kHz (+0 dB, -2.0 dB)
Dynamic range: More than 80 dB (1 kHz, emphasis OFF, “A” weighted)
Distortion; Less than 0.2% (1 kHz, emphasis OFF, reference level)
Crosstaik: Less than -80 dB (1 kHz, between 2 channels)
Wow and fiutter: Below measurable limits
Anaiog output (CH1/CH2): Phono X 2; -8 dBV, 1 kii
Headphones output: М3 stereo, variable level (max. -32 dBV or more), 8Q
PUT CONNECTORS
RF output (CH3/CH4): VIDEO, AUDIO
Wired remote control: M2 jack (simple remote control)
Counter: 8 digits (CTL/TC/UB selectable, remaining tape)
Audio ievei meter: 18 steps
Other: REMOTE, WiDE, “Consumer-use cassette ioaded” display,
REPEAT, SERVO, Channel condition, “Cassette loaded”
display
26-
