Home theater
Upgrading your audio equipment
Setup chart
Types of
connectjon
Equipment and
settings Equipment Speakers
Settings in
‘8 Speaker Setting”
Settings in
“7 Digital Audio
Output”
Page
To enjoy the 5.1-
channel surround
sound found on
DVDs using the
unit’s built-in
decoder^ 1
Amplifier with 5.1-
channel audio input
terminals 'Front speakers (L/R)
'Subwoofer
'Surround speakers
(L/R)
'Center speaker
Select “1 Multi-channel”
•Speaker presences
Set speakers you have
connected to Tes”
• Set delay time if
necessary
•Correct output
balance if necessary
PCM Down
Converslon=^“No”
□
33
To add bass to the
sound from your
televisioni^
Subwoofer No settings required PCM Down
Conversion^ >“No”
ID
34
To enjoy stereo and
added bass^^ Analogue amplifier or
system component
with 2-channel audio
input terminals
•Front speakers (L/R)
• Subwoofer No settings required PCM Down
Conversion=î>“No”
To enjoy stereo
through an analogue
a m p l i f i e r i ^
Front speakers (L/R) Select “2 2-channei” PCM Down
Conversion^‘‘No”
Q
34
□
34
I
To enjoy the 5.1-
channel surround
sound found on DVDs
using the decoder in
another unit
Amplifier with built-in
decoder or a separate
decoder-amplifier
combination^^ ► Front speakers
'Subwoofer
►
Surround speakers
(L/R)
►Center speaker
(L/R) No settings required ►PCM Down
Con versions'Yes”
► Dolby Digital/DTS
Digital Surround/
MPEG
^settings depend on
your decoding
equipment
El
35
To enjoy stereo
through a digital
amplifieras Audio equipment with
digital audio input
terminals Front speakers (L/R) Select “2 2-channer ► PCM Down
Conversion^'Yes”
► Dolby Digital=^“PCM”
► DTS Digital Surround
► MPEG^“PCM”
36
DVD-RV40 only.
^2 DVD-RV20 only.
^3 If you have connected a Dolby Pro Logic amplifier, you may
need to connect center and surround speakers.
•j^4- Connect speakers if necessary and make the speaker settings
on the amplifier.
■ Upgrading your television
•You can connect CRT projectors, LCD projectors, and projection
televisions.
• See “Connection to a television” (^ pages 9 to 11) for details on
connection.
•The equipment connections described are examples. The
illustrations on pages 33, 35 and 36 use DVD-RV40 as an
example, and on pages 34 use DVD-RV20 as an example.
•Additional equipment and cables are not supplied.
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks
of Dolby Laboratories. Confidential Unpublished Works.
© 1992-1997 Dolby Laboratories, Inc. All rights reserved.
For your reference
• Dolby Digital is a digital sound compression technique developed
by Dolby Laboratories.
Supporting 5.1-channel surround sound, as well as stereo (2-
channel) sound, this technique enables a large quantity of sound
data to be efficiently recorded on a disc.
• DTS Digital Surround is a 5.1-channel surround sound system,
which is widely used in movie theaters around the world. The
separation between channels is good and provides a very real
surround effect.
• Linear PCM is an uncompressed digital audio signal. While a CD is
recorded in 44.1 kHz/16 bit, a DVD is recorded in 48 kFlz/16 bit up
to 96 kFlz/24 bit. Therefore, the sound reproduced with these
signals is potentially better than that found on CDs. This player
reproduces linear PCM in 2-channel.
• Bitstream is a compressed digital audio signal. This signal can be
decoded into different channels to produce, for instance, 5.1-
channel surround sound.
•The digital audio output terminal (optical) converts electrical
signals into optical signals and transfers them to an amplifier.
These optical signals are immune to electrica! interference, and
they also have minimal effect on other equipment.
VQT8633
