Panasonic NV-HD675 - Manual (Page 29)

To Select the Desired Tape Speed
Press SPEED before recording.
Display Symbol
SPEED
a
To Interrupt Recording
Press I !/!► (PAUSE/SLOW) during recording.
Press again to continue recording.
О
To Record One TV Programme while
Viewing Another One
1 Refer to steps 1-3 of the manual recording operation.
2 Select the TV programme on your TV that you wish to
view now.
•Ensure that VCR—TV switch is set to TV.
To Display the Approximate Remaining
Tape Time
1 Select TAPE SELECT from the on screen display and
select the corresponding video cassette tape length.
See page 22. Screen Display
;i80)
NTSC INPUT SELECT (AUTO
NTSC PB SELECT (onPALTV)
NTSCCONWEHTEH (OFF)
JET REWIND (ON)
POWER SAVE (OFF
AUDIO MIX (OFF)
CE>
1^ (№NU
El 80: For E30, *60, -90, -120, -150 and -180 tapes.
E195: For El 95 tape.
E240: For E240 tape.
E260: For E260 and -300 tapes.
2 Press DISPLAY.
DISPLAY
( > ■-- ■.
The display changes as follows each time DISPLAY is
pressed.
p>Clock-^Counter-»Remaining Tape Time — |
•The remaining tape time may not be displayed
correctly depending on the tape used.
Notes:
• When a video cassette with a broken off erasure
prevention tab is inserted, the “ga” indication will flash to
indicate that recording is not possible even if REC • (•
REC/OTR) is pressed.
• The recording pause mode will be automatically released
after 5 minutes, and the VCR will return to the stop mode.
ШШ: ywri?i; +
© © ©
SEPBCH.' ■ 050 ■ ОИРШ:-,
ЯЕ
8
ЕТ plWE<-i ВЕС
:Q: ® : a,
-------------
C.uir.i.
SPEED
a 00:05)
АШЮ01Я: .. . veBftv
ООО
Recording of Stereo or Bilingual
Programmes
(NV-HD675A only)
1 Recording is automatically made in the stereo or bilingual
mode. This prevents errors in the selection of the dubbed
or the original language.
2 During playback press AUDIO OUT to select the desired
sound mode. See page 7,
The NICAM Broadcast System
(NV-HD675EA only)
NV-HD675EA is equipped with the NICAM sound system.
NICAM is a 2 channel sound broadcast system to provide
either a high quality stereo sound track or 2 independent
MONO sound tracks, Ml and М2.
NICAM programmes are always accompanied by standard
sound broadcasts and you can select the desired sound
with AUDIO OUT during playback.
• The NICAM digital stereo sound can only be recorded on
the Hi-Fi audio track.
• When NICAM programme is being received, the indicators
are lit to inform you of the type of broadcast.
{See page 21.)
• To record the regular sound (ordinary normal sound) on
the FM audio tracks when a NICAM programme is
received, set MONAURAL to ON. (See page 25.)
• To hear stereo performance connect as shown on page 9
to a TV or Stereo Amplifier with left and right audio inputs.
Important Note for the NICAM System
When NV-HD675EA is switched on, the tuner will
automatically switch to a NICAM broadcast, if NICAM is
being transmitted.
At this time the NICAM signal is transmitted on stereo
channels only, since the Ml and М2 formats are not yet
available. Even if the sound track is in MONO, the stereo
indicator will appear.
CO
c
,o
CD
§
.O
Й
CQ
29
