Specifications
NV-SD1A, EA
Information for Your Safety
Power Source:
Power Consumption:
NV-SD1A; 240 V AC 50-60 Hz
NV-SD1EA; 230 VAC 50-60 Hz
Approx. 21 watts
Video Recording System;
Video Heads:
Tape Speed:
Tape Format:
Record/Playback Time:
VIDEO
Television System:
Modulation System:
Input Level:
Output Level:
AUDIO
Input Level:
Output Level:
Audio Track:
Video Horizontal Resolution;
Signat-to-Noise Ratio:
Audio Frequency Response:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
Standard Accessories:
2 rotary heads, helical scanning system
2 heads
23.39 mm/sec.
VHS tape
240 min. with NV-E240
CCtR; 625 lines, 50 fields, PAL colour signal
Luminance; FM azimuth recording
Colour signal; converted subcarrier phase shift recording
VIDEO IN (PHONO):
1.0 Vp-p,
VIDEO OUT (PHONO): 1.0 Vp-p,
RF Modulated: NV-SDIA: VHF channel 0 or 1,
NV-SD1EA: VHF channel 2 or 3,
AUDIO IN (PHONO);
AUDIO OUT (PHONO);
1 track (Normal-mono only)
Colour; more than 240 fines
Video: more than 43 dB
Audio: more than 43 dB
80 Hz-10 kHz
5"C-40°C
35%-80%
4.3 kg
430 (W)x91 (H)x273 (D) mm
1 pc. DIN-DIN Coaxial Cable
1 pc. Remote Controller
2 pcs. ‘‘R6" “AA” size batteries
1 pc. AC Mains Lead
more than -10 dBV,
-6dBV,
75 ohm
75 ohm
75 ohm
75 ohm
more than 50 kohm
1 kohm
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
