Multi Function Display

VCR Indicator
Lights when the

VCR/TV selector

is set to VCR.

Power Indicator -
Lights when power

is on.

Tinner Indicator

Lights when the VCR is set for a Timer
Recording, or when One Touch Recording
(OTR) is used. Flashes when a Timer
Recording is set, but a tape has not been

inserted into the VCR and when a power
interruption occurs during Timer Programming.

VCR TIMER

'«I ►

•

Function Indicator
Shows what the VCR
is doing.

REC

Playback

REW

^Flashirtg PAUSE

►Flashing SLOW/STILL

► ^^Flashing CUE

Flashing^^^ ►

REV

Rear View of the VCR

AC Power Plug

While plugged into an AC
outlet, the VCR consumes

Audio Input Connector
