SNMP Extensions Application
Application Views 3Com PortSwitch Hubs
5-16 Management Module Guide
See Table 5-6 for possible values and their meanings.
Health Text
Displays a string that provides information on the operational state of the
repeater. This may be used to provide detailed failure information or
instructions for problem resolution.
Partitioned Ports
Displays the number of ports in the repeater whose current state meets all the
following criteria:
• The Port Operational Status does not have the value notPresent
• The Port Administrative Status is enabled
• The Port Auto Partition State is set to autoPartitioned
Group Capacity
Displays the number of groups that can be contained within the repeater.
Within each managed repeater, groups are numbered from 1 to this number.
Some groups may not be present in a given repeater, in which case the actual
number of groups will be less than this number.
In practice, this will generally be the number of modules, cards, or boards that
can fit in the physical repeater enclosure, and the group numbers will
correspond to numbers marked on the physical enclosure.
This button applies the current settings.
This button accesses the RFC1516 Extensions view.
Table 5-6. SNMP-Repeater Operational Status Values
Value Description
other Undefined or unknown
ok No known failures
rptrFailure Repeater related failure
groupFailure Group related failure
portFailure Port related failure
generalFailure An unspecified failure
Reconfigure Application
rfc1516 Extensions
