9032295 E2 Application Views
5-13
RMON Extensions Application
AABBCCDD:112233445566. An error is returned if the agent does not support
the download protocol implied by the address format.
Protocol
Displays the protocol to use when downloading the software. This is
determined from the format of the address in the Server Addr field.
Load
This field is only available in the System Loader Entry view. It is always
displayed as NoAction. Set the value to StartDownLoad to load the new
software as specified in this entry.
RMON Extensions Application
This application supports the RMON Extensions View. The model type for this
application is 3ComRMONExtApp.
RMON Extensions View
This view contains a Poll Table and the following buttons:
Accesses the RMON Extensions Host View described below.
Accesses the RMON Extensions Event Alarm View described below.
Poll Table
This table appears in two windows on the RMON Extensions View. It contains
the following information:
Index
Identifier of a row in the Poll Table.
IP Address
Displays the network address of the device to monitor. Typically this is an IP,
MAC, or IPX address. The following formats can be used.
• IP nnn.nnn.nnn.nnn - dotted format
• MAC AABBCCDDEEFF - hex notation
• IPX AABBCCDD:AABBCCDDEEFF - network : node
Host Tables
Alarm Event Tables
